Key Features
- Dual channel bidirectional I²C bus repeater
- Voltage level translation from 1.08 V to 3.6 V at both port A and port B
- Guaranteed 1 MHz operation (true I²C FM+) and supports FM and SM operations
- No static voltage offset
- Schmitt trigger inputs improve the noise immunity by filtering the noise components of the signals
- Input and output rising-edge signal accelerators at all I/O’s
- Lock-free operation
- Glitch-free and sequence-independent IC power-up
- I²C clock-stretching support
- Open-drain input/outputs
- Compatibility with I²C bus and SMBus protocols
Applications
- Devices for IoT applications
- Cell phones, tablets, laptops
- Portable medical devices,
- Portable instrumentation and test equipment's
- Telecom switching and networking equipment
- Products with many I²C slave devices and / or long PCB trace
- Power-sensitive applications
